Specifications
| Dimensions | Mill Standard |
|---|---|
| Tolerances | EN 10034 |
| Section | Height (mm) | Width (mm) | Web Thickness (mm) | Flange Thickness (mm) | Weight (kg/m) |
| IPE 80 | 80 | 46 | 3.8 | 5.2 | 6 |
| IPE 100 | 100 | 55 | 4.1 | 5.7 | 8.1 |
| IPE 120 | 120 | 64 | 4.4 | 6.3 | 10.4 |
| IPE 140 | 140 | 73 | 4.7 | 6.9 | 12.9 |
| IPE 160 | 160 | 82 | 5 | 7.4 | 15.8 |
| IPE 180 | 180 | 91 | 5.3 | 8 | 18.8 |
| IPE 200 | 200 | 100 | 5.6 | 8.5 | 22.4 |
| IPE 220 | 220 | 110 | 5.9 | 9.2 | 25.3 |
| IPE 240 | 240 | 120 | 6.2 | 9.8 | 29.6 |
| IPE 270 | 270 | 135 | 6.6 | 10.2 | 35.1 |
| IPE 300 | 300 | 150 | 7.1 | 10.7 | 41.3 |
| IPE 330 | 330 | 160 | 7.5 | 11.5 | 47.4 |
| IPE 360 | 360 | 170 | 8 | 12.7 | 53.8 |
| IPE 400 | 400 | 180 | 8.6 | 13.5 | 61.3 |
