Specifications
| Dimensions | DIN 1026-1 |
|---|---|
| Tolerances | EN 10279 |
| Section | Height (mm) | Width (mm) | Web Thickness (mm) | Flange Thickness (mm) | Weight (kg/m) |
| UPE 80 | 80 | 50 | 4.5 | 8 | 7.05 |
| UPE 100 | 100 | 55 | 5 | 8.5 | 8.64 |
| UPE 120 | 120 | 60 | 5.5 | 9 | 10.4 |
| UPE 140 | 140 | 65 | 6 | 9.5 | 12.5 |
| UPE 160 | 160 | 70 | 6.5 | 10 | 14.8 |
| UPE 180 | 180 | 75 | 7 | 10.5 | 17.3 |
| UPE 200 | 200 | 80 | 7.5 | 11 | 17.2 |
| UPE 220 | 220 | 85 | 8 | 12 | 20 |
| UPE 240 | 240 | 90 | 8.5 | 13 | 22.7 |
| UPE 270 | 270 | 95 | 9 | 14 | 26.2 |
| UPE 300 | 300 | 100 | 9.5 | 15 | 29.9 |
| UPE 330 | 330 | 105 | 11 | 16 | 35.1 |
| UPE 360 | 360 | 110 | 12 | 17 | 40.2 |
| UPE 400 | 400 | 115 | 13.5 | 18 | 46.2 |
